PRO 3 PLUS COLORApertura Measurement aperture: 8 mm (0.31”) diameter (effective measurement aperture during scanning is depending on the patch size and measurement speed)

Espacio en disco disponible 2GB
Calibración Manual on external ceramic white reference (included)
Interfaz de comunicación USB 1.1
Conectividad Powered USB port
Dimensiones (largo, ancho, alto) i1Pro device: 162 mm x 69 mm x 64 mm (6.4” x 2.7” x 2.5”)
Resolución de la pantalla 1024×768 pixels or higher
Nivel de experiencia Intermediate to Advanced
Humedad 30 to 85% RH (non-condensing)
Tamaño del área de iluminación 12 mm (0.47”)
Acuerdo entre instrumentos 0.3 ∆E00* average, 0.8 ∆E00* max. (deviation from X-Rite manufacturing standard at a temperature of 23ºC (73.4ºF) on 12 BCRA tiles (D50, 2º))
Conexión a Internet Required for software install, download and automatic update
Idiomas compatibles Chinese (Simplified), English, French, German, Italian, Japanese, Korean, Portuguese, Spanish
Fuente de luz i1Pro3 Plus LED Illumination (including UV)
Macintosh MacOS X 10.11x, 10.12x or 10.13x (with latest upgrades installed)
Condiciones de medición • M0 – UV included – ISO 13655:2017
• M1 – D50 – ISO 13655:2017
• M2 – UV excluded Filter – ISO 13655:2017
• M3 – Polarization – ISO 13655:2017
Frecuencia de la medición en el modo de escaneo 400 measurements per second
Geometría de medición 45°:0° ring illumination optics, ISO 13655:2017
Zona de medición 8mm (0.315”)
Media Thickness 1mm or less
Memoria 2GB Minimum
Cantidad de pantallas admitidas por estación de trabajo Up to 4
Rango de temperatura de operación 10°C to 35°C
50°F to 95°F
Tamaño del parche Minimal Patch Size in Scanning Mode: 16 x 16 mm (0.63” x 0.63”) (Width x Height) with sensor ruler 20 x 16 mm (0.79” x 0.63”) (Width x Height) without sensor ruler
Rango fotométrico 10nm; Sampling interval 3.5nm
Procesador MAC: Intel® Core 2 Duo CPU or better; WINDOWS: Intel® Core 2 Duo or AMD Athlon™ XP or better
Longitud de escaneo Maximum 515mm (20.28″)
Compatible con el objetivo del escáner Yes
Capacidad de escaneo Yes
Seguridad User must have Administrator rights to install and uninstall the application
Repetitividad de corto plazo: blanco 0.05 ∆E00 on white (D50,2°, mean of 10 measurements every 3 seconds on white)5
Kit de desarrollo de software Available for OEM customers
Analizador de espectro i1® technology with built-in wavelengths check; Holographic diffraction grating with 128-pixel diode array
Intervalo espectral 380 – 730 nm
Presentación del espectro 380 … 730 nm in 10 nm steps
Rango de temperatura de almacenamiento -20° to 50°C
-4° to 122°F
Formato de perfil compatible ICC version 2, version 4.3, & iccMax
Unité de couleur Black/Silver
Experiencia de usuario Choose between a ‘basic’, wizard-driven interface or an ‘advanced’, user-driven interface for highest level professional results
Tarjeta de video
MAC: Latest drivers for video card installed

WINDOWS: Latest drivers for video card installed, dual display support requires either 2 video cards or a dual head video card that supports dual video LUTs being loaded

Garantía Twelve (12) months from the date of sale, unless different local regulations apply. Product registration is required to receive X-Rite technical support during the warranty period. Registration can occur directly through the software, on our website, or via phone. Users are encouraged to register their product within the first 30 days of use.
Peso i1Pro device: 285 g (10.1 oz)
¿Qué incluye? i1Pro 3 Plus spectrophotometer (measurement device), calibration plate, polarizing filter, ambient light measurement head, monitor holder, positioning target, XL scanning ruler, XL backer board, USB cable. i1Profiler v3.x software for monitor profiling plus QA for monitors and printers, PANTONE Color Manager software.
Windows Windows 7, 8, 8.1, 10 (with latest Service Pack installed)
